WMHPC-80-520M-10dB-N

Werbel Microwave Model WMHPC-80-520M-10dB-N is a high-power coupler that operates over the 80-520MHz band, covering FM radio, upper VHF and lower UHF applications. Rated for 200 watts CW. Useful for amplification and signal distribution applications including radio and television broadcasting, public safety and emergency broadcasting and distributed antenna systems. There exists a roll down of 2dB at the low frequency, making the nominal coupling value 12dB within the FM radio band. Mainline loss 1.2dB typical which includes the loss due to coupling. Typical return loss 33.2dB. Typical directivity 28.3dB.
